Single-Ply membranes


Single-ply membranes are factory-manufactured sheet membranes. They generally are categorized as either thermoplastic or thermoset. Thermoplastic materials can be repeatedly softened when heated and hardened when cooled. Thermoset materials solidify, or "set," irreversibly after heating. Single ply membranes commonly are referred to by their chemical acronyms, such as ethylene propylene diene terpolymer (EPDM).
Single-ply sheet membranes are produced using one of three manufacturing processes: calendering, extruding or spread coating. The membranes may contain reinforcement layers. Common reinforcements for single ply membranes include polyester fabrics or scrims, glass fiber, or a felt or fleece backing.
A finished sheet's thickness typically is referred to as mil thickness; 1 mil equals 0.001 inch. Common mil thicknesses for these sheet membranes range from 30 mils to 60 mils.
Single-ply membranes can be installed fully adhered, mechanically attached or held down with ballast. Most single-ply roof systems do not receive surfac
In many instances, a combination of attachment methods are used to secure a roof system. For instance, an insulation may be mechanically attached to the substrate with the roof membrane fully adhered to the insulation.


Most commercial and residential flat roofs in South Florida have some kind of ponding/pooling water on them and this can create a problem in both the short and long run.

Gaco Western developed a product that concurred the water ponding dilemma. Some roof coating offer reflectivity components, others are water proofing coatings, and some are resistant to ponding water, Gaco Western products offers all three.
Our company is certified Gaco Western applicators and are able to offer our clients 10 and 20 year warranties backed  by Gaco,

Modified Bitumen Roofs


Modified Bitumen (MB) roofing is an asphalt-based, close cousin of the Built-up-Roof (BUR) designed for buildings with low-slope or “flat” roof structures. Engineered modified bitumen roofing membranes originated in Europe in the mid 1960's and have been used successfully in the United States and Canada since approximately 1975.

Increased resistance to brittleness at cold temperatures, greater flow resistance at high temperatures, and increased elasticity can be achieved by blending synthetic rubberized polymers with asphalt in lieu of modification by the blowing process used for BUR asphalt. There are numerous surfacing options for this system which include a factory applied mineral surface, gravel surface, including “cool roof” coatings which are highly-reflective to save on building cooling costs. Mineral-surfaced MB products are typically furnished with white granules, but are also available in designer colors to match asphalt shingles or to otherwise compliment the building design.

MB gives designers and installers an even broader array of options than BUR. MB may be installed by the torch-application method, or “hot-mopped” like BUR, or applied with “cold-process” adhesives. The latest innovation with MB is the self-adhering sheet. Using special combinations of polymers to modify the underside of the MB sheet, the rolls are manufactured with a release paper. The installer removes the release paper and as the sheet is rolled out, it adheres itself to the substrate. This method eliminates the risks associated with the use of torches, hot asphalt, and is completely free of VOC (volatile organic chemicals) fumes during and after application
.


Built Up Roofs


Built up roof membranes, referred to by the acronym BUR, have been in use in the U.S. for more than 100 years. These roof systems are commonly referred to as "tar and gravel" roofs. BUR systems generally are composed of alternating layers of bitumen and reinforcing fabrics that create a finished membrane. The number of plies in a cross section is the number of plies on a roof: The term "four plies" denotes a four ply roof membrane construction. Sometimes, a base sheet, used as the bottom most ply, is mechanically fastened. Built up roofs generally are considered to be fully adhered if applied directly to roof decks or insulation.

The reinforcing fabrics also are called roofin felts or ply sheets. Roofing felts are reinforced with either glass-fiber mats or organic mats. Felts are produced in a standard width of 36 inches and metric width of about one meter.

The bitumen typically used in BUR roof systems is asphalt, coal tar or cold-applied adhesive. The asphalt or coal tar is heated in a kettle or tanker and then applied by mop or mechanical spreader.  Cold-applied adhesives typically are solvent-based asphalts that don't have to be heated in a kettle or tanker.

Surfacings for built up roof systems include aggregate (such as gravel, slag or mineral granules), glass-fiber or mineral surfaced cap sheets, hot asphalt mopped over the entire surface, aluminum coatings or elastomeric coatings
.


Types of Flat roofs

  • Built Up Roofs

 • Modified Bitunum Roofs

 • Single Ply Roofs

      -TPO

      -EPDM

      -PVC

 •Coatings



Flat Roofs and Coatings
